| interface |
Control System: Based on Embedded LinuxDisplay screen size: 4.5-inch color capacitive touch screenOperation mode: Chinese/English and other multi language interfaceBuilt in editing: supports OX Script printing templates and logic customizationPrompt system: status indicator light, touch warning prompt, fault information feedback |
| Interface and Communication |
Host interface: RS-232 serial port/USB Device 2.0/USBHost/Gigabit Ethernet (RJ45)Control interface: 24 pin logic I/O control port+15 pin universalI/O portInput signals: print trigger, product detection, synchronizer signalOutput signals: printing completed, labeling completed, alarm output, statussignalWireless communication (optional): Wi Fi (802.11 a/b/g/n/ac/ax, 2.4/5GHz), Bluetooth 5.0 |
| Printing performance |
Printing method: thermal/heat transfer printing)Resolution: 300 dpi (11.8 dots/mm)600dpi (optional)Maximum printing speed: 14 ips (355.6 mm/s)6ips (152.4mm/s) (optional 600dpi)10 IPS (254 mm/s) (optional 6-inch model)Effective printing width: 4.16 "(105.7 mm)6.6 "(168 mm) (optional 6-inch model)Maximum printing length: 196 inches (5000 mm)118 "(3000 mm) (optional 6-inch model)Print head technology: HEAT ™ Intelligent Thermal Balance Control (Level I)Calibration function: ADAPT ™ Precision paper feeding calibration systemBarcode types: Code 39, 93, 128, EAN, UPC, QR Code,DataMatrix and othersFont support: 5 built-in dot matrix fonts, 2 scalable fonts(including GB2312 Chinese); Support TrueType font downloadRFID function (optional): Supports UHF EPC Gen2/ISO18000-6C |
| Electrical and Environmental Requirements |
Power input: AC 100-240V, 50/60HzPower consumption: approximately 300W (typical value)Working environment: temperature 0-40 ° C; humidity 5-90% RH (no condensation)Storage environment: Temperature -40-60 ° C; Humidity 5-90% RH(No condensation) Altitude: ≤ 5000 meters |
| Overall dimensions |
515(W) × 406(D) × 366(H) mmLabel roll size: maximum outer diameter of 12 "(304.8 mm)Inner diameter 1.5 "(38 mm)/3" (76.2 mm)Width 10-120mm (maximum 4.72 inches)Width 30-180 mm (maximum 7.09 inches) (optional 6-inch model) |
| Label and carbon ribbon specifications |
Equipped with label roll supply deviceBottom paper recycling: maximum outer diameter of 7.87 "(200 mm)Carbon ribbon specification: Width 0.79 ″ -4.33 ″ (20-110 mm)30-176 mm (optional 6-inch model)Maximum length 1968 '(600 m)Outer diameter 3.38 "(86 mm),Inner diameter 1 "(25.4 mm), both inner and outer carbon can be usedPaper detection method: Up reflection/Down reflection/Penetrating (continuous paperGap, with holes)Label thickness: 0.06-0.305 mm (including backing paper)Minimum label height: 5 mm for tearing mode, 12 mm for peeling modePaper tearing mode 15mm, paper peeling mode 12mm (optional 6-inch model) |
| Optional configuration |
RFID code verification systemVisual verification system (barcode level detection/defect recognition)Carbon ribbon saving component wireless communication module (Wi Fi/Bluetooth) |
| Standard Configuration |
Printing and labeling host x 1Power cord, I/O interface cable package x 1Operating system and basic softwareOnline template editing function (built-in OX Script)User manual and test label consumables kit x 1 |
| Safety Certification |
Electrical safety: Complies with CE certification standards Laser safety: Complies with Class 1 laser safety standards (if applicable) Protection level: IP54 Protection level |
| Quality Certification |
Complete machine warranty: 1-year limited warrantyProduct standard: Complies with the manufacturing specifications for industrial printing and labeling systems (EN/IEC standards) |
| Labeling component selection |
Brushing, single cylinder pressure pasting, dual cylinder pressure pasting, triple cylinder pressure pasting, blowing pasting |
